pcProx非接触式智能卡读卡器

产品介绍:

超小型pcprox 13.56兆赫nano非接触式智能卡读卡器,以及125千赫的接近式移动读卡器,为移动工作者提供了安全性、易识别性以及对其USB笔记本电脑或平板电脑的简单访问。pcprox nano紧凑的外形使其成为嵌入式应用(外壳、键盘、控制面板)的一个流行选择,以最小化硬件部件。

pcprox 13.56兆赫nano以流行的垂直形状系数提供。pcprox 125 kHz nano可提供垂直或水平形状系数。革命性的小规模在解决方案多样性和集成方面带来了巨大的机会和灵活性。向后兼容性确保了与现有徽章系统的组织的简单集成。(有关更多信息,请联系您的区域销售经理。了解您所在地区的销售经理。)

概述

Rf Ideas的PCProx Enroll读卡器专为寻求利用现有卡系统进行建筑物访问以外的应用的客户设计。这些读卡器经过精心设计,可以与几乎所有的接近和非接触式智能卡技术一起工作。13.56兆赫型号与大多数非接触式智能卡兼容,125千赫接近型号为全球使用的3亿多个物理访问卡提供无错误识别。

具有即插即用功能、无需软件和嵌入式可配置闪存,这些读卡器已准备好与几乎所有操作系统、应用程序和嵌入式控制器集成。

PCProx 82系列读卡器通过使用RF Ideas Universal Software Developer's Kit(SDK)集成到您的软件或硬件产品中。与注册读卡器不同,82系列使用可调用的DLL或其他直接集成方法,而不是键控(模拟键盘设备)。这些低成本的读卡器以应用程序识别的格式提供卡ID,为用户识别和身份验证提供了几乎无限的可能性。

优点

· 改善工作流程

· 消除与个人识别相关的错误

· 消除手动输入

· 可定制,适用于任何规模公司的任何卡解决方案

· 保护和保护敏感信息

· 满足各种行业合规性要求(与适当的应用解决方案一起使用时)

· 员工熟悉现有徽章

· 支持几乎所有卡类型技术

· 增加单徽章的投资

· 扩展应用程序选择

应用

· PC / LAN访问控制

· 应用程序登录

· 员工识别

· PLC和嵌入式控制器

· OEM

· 时间和出勤

· 会议出席,访客管理

· 旅馆

· 安全打印

· 销售点

· 分配

· 移动

· 采集

特征

· 连接器和软件接口

标准USB型号(Enroll)直接连接到USB端口,可以按键发送数据或使用可选的软件开发工具包(SDK)。RS-232型号连接到标准串行PC COM端口,并以ASCII格式发送数据。CDC模型模拟虚拟串行设备。

注意:要在某些型号中使用PoE和E / IP功能,可能需要使用C-6200适配器

· 兼容性

与WindowsXP®,7®,8®,10®和Linux Ubuntu 12.04兼容。(Windows®操作系统上需要免费配置软件)。

· 提高信息和生产率的准确性

消除与个人识别相关的错误。

· 多种安装选项

标准桌面外壳可轻松放置在桌面表面或安装在自助服务终端,显示器,时钟等设备上。在新的USB纳米 外壳容易直接插入任何笔记本电脑或平板电脑上的USB端口。

*还提供表面贴装设计。

· 即插即用安装

· 完全可编程和可定制的用户定义字段

· 与全球数百万张卡兼容

连接器和软件接口

标准USB模型(注册)连接直接地到USB口岸,并且可能送数据作为击键或与任意软件开发套件(SDK)一起使用。 RS-232模型连接到一个标准连续个人计算机COM口岸并且送数据作为ASCII。 CDC模型模拟虚拟串行设备。

注意:要使用某些型号的PoE和E/IP功能,可能需要使用C-6200适配器

兼容性

与Windows XP兼容, 7, 8, 10 和Linux Ubuntu12.04. (在Windows操作系统上需要免费的配置软件)。

提高信息的准确性和生产率

消除与个人识别相关的错误。

多才多艺的架置选择

标准桌面住房考虑到容易的安置在桌面表面或登上在报亭、显示器、时间钟表和更多。 新的USB Nano住房容易地直接地塞住入所有膝上型计算机或片剂与USB口岸。

*也可在表面贴装设计。

即插即用安装

完全可编程和可自定义的用户自定义字段

兼容数以百万计的卡在全球范围内使用

符合行业标准

当读取器用作访问控制应用程序的一部分时,可以轻松满足隐私和安全访问的合规性要求。读者可以轻松收集所需合规报告的员工信息。pcProx通常用作符合HIPAA标准的解决方案的一部分,用作登录阅读器。在执法和刑事司法组织中,包含pcProx读卡器的解决方案有助于控制对只允许授权人员查看的各种数据库的访问。在食品加工行业,风险评估和风险管理是FDA危害分析和关键控制点(HACCP)管理系统所讨论的整体风险管理过程的两个关键要素。

· 医疗/医疗保健HIPAA兼容

当用作登录读卡器时

· 符合CJIS标准的

解决方案采用pcProx读卡器,可帮助执法和刑事司法组织了解合规性要求·

仅符合IP67标准的 pcProx和pcProx Plus表面贴装 - 当IP67表面贴装读卡器按照IP67表面贴装说明书指南安装时

产品型号:

pcProx 125 kHz USB Part Numbers

USBDescription

RDR-6712AKUpcProx 125 kHz 82 Series Kantech/ioProx Vertical Nano USB

RDR-6011AKUpcProx 125 kHz HID™ Prox Black Vertical Nano USB

RDR-6012AKUpcProx 125 kHz 82 Series HID™ Prox Black Vertical Nano USB

RDR-6021AKUpcProx 125 kHz HID™ Prox Black Horizontal Nano USB

RDR-6022AKUpcProx 125 kHz 82 Series HID™ Prox Black Horizontal Nano USB

RDR-6E22AKUpcProx 125 kHz 82 Series EM 410x Black Horizontal Nano USB

RDR-6E12AKUpcProx 125 kHz 82 Series EM 410x Black Vertical Nano USB

RDR-6E11AKUpcProx 125 kHz EM 410x Black Vertical Nano USB

RDR-6E21AKUpcProx 125 kHz EM 410x Black Horizontal Nano USB

RDR-6922AKUpcProx 125 kHz AWID 82 Series Black Horizontal Nano USB

RDR-6912AKUpcProx 125 kHz AWID 82 Series Black Vertical Nano USB

RDR-6921AKUpcProx 125 kHz AWID Black Horizontal Nano USB

RDR-6911AKUpcProx 125 kHz AWID Black Vertical Nano USB

RDR-6222AKUpcProx 125 kHz CASI-RUSCO 82 Series Black Horizontal Nano USB

RDR-6212AKUpcProx 125 kHz CASI-RUSCO 82 Series Black Vertical Nano USB

RDR-6221AKUpcProx 125 kHz CASI-RUSCO Black Horizontal Nano USB

RDR-6211AKUpcProx 125 kHz CASI-RUSCO Black Vertical Nano USB

RDR-6081AKUpcProx 125 kHz HID™ Prox Black Desktop USB

RDR-6081APUpcProx 125 kHz HID™ Prox Pearl Desktop USB

RDR-6082AKUpcProx 125 kHz 82 Series HID™ Prox Pearl Desktop USB

RDR-60D1AKUpcProx 125 kHz HID™ Prox Black USB Dongle

RDR-60D2AKUpcProx 125 kHz 82 Series HID™ Prox Black USB Dongle

RDR-60N1AKUpcProx 125 kHz HID™ Prox Non-Housed USB

RDR-60N2AKUpcProx 125 kHz HID™ Prox Non-Housed USB

RDR-60W1AKUpcProx 125 kHz HID™ Prox Black Surface Mount USB

RDR-60W2AKUpcProx 125 kHz 82 Series HID™ Prox Black Surface Mount USB

RDR-6281APUpcProx 125 kHz Casi-Rusco Pearl Desktop USB

RDR-6281AKUpcProx 125 kHz Casi-Rusco Black Desktop USB

RDR-6282AKUpcProx 125 kHz 82 Series Casi-Rusco Black Desktop USB

RDR-62W1AKUpcProx 125 kHz Casi-Rusco Black Surface Mount USB

RDR-62W2AKUpcProx 125 kHz 82 Series Casi-Rusco Black Surface Mount USB

RDR-62D1AKUpcProx 125 kHz Casi-Rusco Black USB Dongle

RDR-62D2AKUpcProx 125 kHz 82 Series Casi-Rusco Black USB Dongle

RDR-6D82AKUpcProx 125 kHz 82 Series Diester Black Desktop

RDR-6311AKUpcProx 125 kHz Indala Black Vertical Nano USB

RDR-6312AKUpcProx 125 kHz 82 Series Indala Black Vertical Nano USB

RDR-6321AKU pcProx 125 kHz Indala Black Horizontal Nano USB

RDR-6322AKUpcProx 125 kHz 82 Series Indala Black Horizontal Nano USB

RDR-63D1AKUpcProx 125 kHz Indala Black USB Dongle

RDR-63D2AKUpcProx 125 kHz 82 Series Indala Black USB Dongle

RDR-6371AKUpcProx 125 kHz Indala Black Desktop

RDR-6381AKUpcProx 125 kHz Indala Black Desktop USB

RDR-6381APUpcProx 125 kHz Indala Pearl Desktop USB

RDR-6382AKUpcProx 125 kHz 82 Series Indala Black Desktop USB

RDR-63N1AKUpcProx 125 kHz Indala Non-Housed USB

RDR-63W1AKUpcProx 125 kHz Indala Black Surface Mount USB

RDR-63W2AKUpcProx 125 kHz 82 Series Indala Black Surface Mount USB

RDR-6471AKUpcProx 125 kHz Pyramid Black Desktop USB

RDR-6781AKUpcProx 125 kHz Kantech/ioProx Black Desktop USB

RDR-6781APUpcProx 125 kHz Kantech/ioProx Pearl Desktop USB

RDR-6782AKUpcProx 125 kHz 82 Series Kantech/ioProx Black Desktop USB

RDR-67D1AKUpcProx 125 kHz Kantech/ioProx Black USB Dongle

RDR-67D2AKUpcProx 125 kHz 82 Series Kantech/ioProx Black USB Dongle

RDR-67N1AKUpcProx 125 kHz Kantech/ioProx Non-Housed USB

RDR-67W1AKUpcProx 125 kHz Kantech/ioProx Black Surface Mount USB

RDR-6981AKUpcProx 125 kHz AWID Black Desktop USB

RDR-6981APUpcProx 125 kHz AWID Pearl Desktop USB

RDR-6982AKUpcProx 125 kHz 82 Series AWID Black Desktop USB

RDR-69D1AKUpcProx 125 kHz AWID Black USB Dongle

RDR-69D2AKUpcProx 125 kHz 82 Series AWID Black USB Dongle

RDR-69N1AKUpcProx 125 kHz AWID Non-Housed USB

RDR-69W1AKUpcProx 125 kHz AWID Black Surface Mount USB

RDR-69W2AKUpcProx 125 kHz 82 Series AWID Black Surface Mount USB

RDR-6A81AKUpcProx 125 kHz IDTECK 64 Bit Black Desktop USB

RDR-6A81AKU-128pcProx 125 kHz IDTECK 128 Bit Black Desktop USB

RDR-6C81AKUpcProx 125 kHz Cardax Black Desktop USB

RDR-6D81BKUpcProx 125 kHz Deister Black Desktop USB

RDR-6E81AKUpcProx 125 kHz EM 410x/Rosslare Black Desktop USB

RDR-6E81APUpcProx 125 kHz EM 410x/Rosslare Pearl Desktop USB

RDR-6E82AKUpcProx 125 kHz 82 Series EM 410x/Rosslare Black Desktop USB

RDR-6ED1AKUpcProx 125 kHz EM 410x/Rosslare Black USB Dongle

RDR-6ED2AKUpcProx 125 kHz 82 Series EM 410x/Rosslare Black USB Dongle

RDR-6EW1AKUpcProx 125 kHz EM 410x/Rosslare Black Surface Mount USB

RDR-6EW2AKUpcProx 125 kHz 82 Series EM 410x/Rosslare Black Surface Mount USB

RDR-6G81AKUpcProx 125 kHz G-Prox II Black Desktop USB

RDR-6G82AKUpcProx 125 kHz 82 Series G-Prox II Black Desktop USB

RDR-6H81AKUpcProx 125 kHz HiTag Black Desktop USB

RDR-6H81APUpcProx 125 kHz HiTag Pearl Desktop USB

RDR-6H82AKUpcProx 125 kHz 82 Series HiTag Black Desktop USB

RDR-6HD1AKUpcProx 125 kHz HiTag Black USB Dongle

RDR-6K81AKUpcProx 125 kHz Keri Black Desktop USB

RDR-6K81APUpcProx 125 kHz Keri Pearl Desktop USB

RDR-6K82AKUpcProx 125 kHz 82 Series Keri Black Desktop USB

RDR-6KD1AKUpcProx 125 kHz Keri Black USB Dongle

RDR-6KW1AKUpcProx 125 kHz Keri Black Surface Mount USB

RDR-6N81AKUpcProx 125 kHz NexWatch (NexKey) Black Desktop USB

RDR-6N81APUpcProx 125 kHz NexWatch (NexKey) Pearl Desktop USB

RDR-6N82AKUpcProx 125 kHz 82 Series NexWatch (NexKey) Black Desktop USB

RDR-6ND1AKUpcProx 125 kHz NexWatch (NexKey) Black USB Dongle

RDR-6NN1AKUpcProx 125 kHz NexWatch (NexKey) Non-Housed USB

RDR-6NW1AKUpcProx 125 kHz NexWatch (NexKey) Black Surface Mount USB

RDR-6Z81AKUpcProx 125 kHz SecuraKey Black Desktop USB

RDR-6Z82AKUpcProx 125 kHz 82 Series SecuraKey Black Desktop USB

RDR-6R81AKUpcProx 125 kHz ReadyKey Black Desktop USB

RDR-6R82AKUpcProx 125 kHz 82 Series ReadyKey Black Desktop USB

RDR-6T81AKUpcProx 125 kHz Cotag Black Desktop USB

RDR-6T82AKUpcProx 125 kHz 82 Series Cotag Black Desktop USB

KB-KSI-1700-GHB-3pcProx 125 kHz HID™ Prox Black Keyboard USB

pcProx 125 kHz ExpressCard Part Numbers

ExpressCardDescription

RDR-60E1AKUpcProx 125 kHz HID™ Prox ExpressCard

RDR-60E2AKUpcProx 125 kHz 82 Series HID™ Prox ExpressCard

RDR-63E2AKUpcProx 125 kHz 82 Series Indala ExpressCard

RDR-67E2AKUpcProx 125 kHz 82 Series ioProx ExpressCard

RDR-69E2AKUpcProx 125 kHz 82 Series AWID ExpressCard

RDR-6EE2AKUpcProx 125 kHz 82 Series EM410x ExpressCard

pcProx 125 kHz PCMCIA Part Numbers

PCMCIADescription

RDR-60P1AKPpcProx 125 kHz HID™ Prox PCMCIA

RDR-60P2AKPpcProx 125 kHz 82 Series HID™ Prox PCMCIA

RDR-63P1AKPpcProx 125 kHz Indala PCMCIA

RDR-63P2AKPpcProx 125 kHz 82 Series Indala PCMCIA

RDR-67P2AKPpcProx 125 kHz 82 Series ioProx PCMCIA

RDR-69P1AKPpcProx 125 kHz AWID PCMCIA

RDR-69P2AKPpcProx 125 kHz 82 Series AWID PCMCIA

RDR-6EP2AKPpcProx 125 kHz 82 Series EM410x PCMCIA

pcProx 125 kHz Ethernet Part Numbers

EthernetDescription

RDR-6081AKB-PpcProx 125 kHz HID™ Prox Black Desktop Ethernet Indust. Protocol PoE

RDR-6081AKEpcProx 125 kHz HID™ Prox Black Desktop Ethernet ASCII

RDR-6381AKEpcProx 125 kHz Indala Black Desktop Ethernet ASCII

RDR-63W1AKEpcProx 125 kHz Indala Black Surface Mount Ethernet ASCII

pcProx 125 kHz Serial Part Numbers

SerialDescription

RDR-6081AK0pcProx 125 kHz HID™ Prox Black Desktop USB CDC Virtual COM

RDR-6081AP0pcProx 125 kHz HID™ Prox Pearl Desktop USB CDC Virtual COM

RDR-6082AK0pcProx 125 kHz 82 Series HID Prox Black Desktop USB CDC Virtual COM

RDR-6081AK2pcProx 125 kHz HID™ Prox Black Desktop Serial 5V PS2 RS232

RDR-6081AK5pcProx 125 kHz HID™ Prox Black Desktop Serial 5V Pin 9 RS232

RDR-6081AK6pcProx 125 kHz HID™ Prox Black Desktop Serial 9V Pin 9 RS232

RDR-6081AK7pcProx 125 kHz HID™ Prox Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6081AK8pcProx 125 kHz HID™ Prox Black Desktop Serial 5V Ext Pwr Supply RS232

RDR-6081AK9pcProx 125 kHz HID™ Prox Black Desktop Serial 5V USB Power Tap RS232

RDR-60N1AK0pcProx 125 kHz HID™ Prox Non-Housed USB CDC Virtual COM

RDR-60N1AK2pcProx 125 kHz HID™ Prox Black Non-Housed Serial 5V PS2 RS232

RDR-60N1AK5pcProx 125 kHz HID™ Prox Non-Housed Serial 5V Pin 9 RS232

RDR-60N1AK7pcProx 125 kHz HID™ Prox Non-Housed Serial 9V Ext Pwr Supply RS232

RDR-60N1AK8pcProx 125 kHz HID™ Prox Non-Housed Serial 5V Ext Pwr Supply RS232

RDR-60N1AK9pcProx 125 kHz HID™ Prox Non-Housed Serial 5V USB Power Tap RS232

RDR-60W1AK0pcProx 125 kHz HID™ Prox Black Surface Mount USB CDC Virtual COM

RDR-60W1AW0pcProx 125 kHz HID™ Prox White Surface Mount USB CDC Virtual COM

RDR-60W1AK7pcProx 125 kHz HID™ Prox White Surface Mount 9V Ext Pwr Supply RS232

RDR-60W1AK8pcProx 125 kHz HID™ Prox Black Surface Mount Serial 5V Ext Pwr Supply RS232

RDR-6281AK0pcProx 125 kHz Casi-Rusco Black Desktop USB CDC Virtual COM

RDR-6281AK2pcProx 125 kHz Casi-Rusco Black Desktop Serial 5V PS2 RS232

RDR-6281AK5pcProx 125 kHz Casi-Rusco Black Desktop Serial 5V Pin 9 RS232

RDR-6281AK6pcProx 125 kHz Casi-Rusco Black Desktop Serial 9V Pin 9 RS232

RDR-6281AK7pcProx 125 kHz Casi-Rusco Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6281AK8pcProx 125 kHz Casi-Rusco Black Desktop Serial 5V Ext Pwr Supply RS232

RDR-6282AK7pcProx 125 kHz 82 Series Casi-Rusco Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-62W1AK0pcProx 125 kHz Casi-Rusco Black Surface Mount USB CDC Virtual COM

RDR-62W1AK2pcProx 125 kHz Casi-Rusco Black Surface Mount Serial 5V PS2 RS232

RDR-62W1AK5pcProx 125 kHz Casi-Rusco Black Surface Mount Serial 5V Pin 9 RS232

RDR-62W1AK8pcProx 125 kHz Casi-Rusco Black Surface Mount Serial 5V Ext Pwr Supply RS232

RDR-62W1AW2pcProx 125 kHz Casi-Rusco White Surface Mount Serial 5V PS2 RS232

RDR-62W2AK5pcProx 125 kHz 82 Series Casi-Rusco Black Surface Mount Serial 5V Pin 9 RS232

RDR-6381AK0pcProx 125 kHz Indala Black Desktop USB CDC Virtual COM

RDR-6382AK0pcProx 125 kHz 82 Series Indala Black Desktop USB CDC Virtual COM

RDR-6381AK2pcProx 125 kHz Indala Black Desktop Serial 5V PS2 RS232

RDR-6381AK5pcProx 125 kHz Indala Black Desktop Serial 5V Pin 9 RS232

RDR-6381AK6pcProx 125 kHz Indala Black Desktop Serial 9V Pin 9 RS232

RDR-6381AK7pcProx 125 kHz Indala Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6381AK8pcProx 125 kHz Indala Black Desktop Serial 5V Ext Pwr Supply RS232

RDR-6381AK9pcProx 125 kHz Indala Black Desktop Serial 5V USB Power Tap RS232

RDR-63N1AK2pcProx 125 kHz Indala Non-Housed Serial 5V PS2 RS232

RDR-63N1AK5pcProx 125 kHz Indala Non-Housed Serial 5V Pin 9 RS232

RDR-63W1AK0pcProx 125 kHz Indala Black Surface Mount USB CDC Virtual COM

RDR-63W1AK2pcProx 125 kHz Indala Black Surface Mount Serial 5V PS2 RS232

RDR-63W1AK5pcProx 125 kHz Indala Black Surface Mount Serial 5V Pin 9 RS232

RDR-63W1AK7pcProx 125 kHz Indala Black Surface Mount Serial 9V Ext Pwr Supply RS232

RDR-6471AK2pcProx 125 kHz Pyramid Black Desktop Serial 5V PS2 RS232

RDR-6471AK5pcProx 125 kHz Pyramid Black Desktop Serial 5V Pin 9 RS232

RDR-6781AK0pcProx 125 kHz Kantech/ioProx Black Desktop USB CDC Virtual COM

RDR-6781AK2pcProx 125 kHz Kantech/ioProx Black Desktop Serial 5V PS2 RS232

RDR-6781AK5pcProx 125 kHz Kantech/ioProx Black Desktop Serial 5V Pin 9 RS232

RDR-6781AK7pcProx 125 kHz Kantech/ioProx Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-67W1AK2pcProx 125 kHz Kantech/ioProx Black Surface Mount Serial 5V PS2 RS232

RDR-67W1AK7pcProx 125 kHz Kantech/ioProx Black Surface Mount Serial 9V Ext Pwr Supply RS232

RDR-6981AK0pcProx 125 kHz AWID Black Desktop USB CDC Virtual COM

RDR-6981AK2pcProx 125 kHz AWID Black Desktop Serial 5V PS2 RS232

RDR-6981AK5pcProx 125 kHz AWID Black Desktop Serial 5V Pin 9 RS232

RDR-6981AK7pcProx 125 kHz AWID Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6981AK8pcProx 125 kHz AWID Black Desktop Serial 5V Ext Pwr Supply RS232

RDR-69W1AK2pcProx 125 kHz AWID Black Surface Mount Serial 5V PS2 RS232

RDR-6A81AK0pcProx 125 kHz RF Logics/ID Teck Black Desktop USB CDC Virtual COM

RDR-6C81AK0pcProx 125 kHz Cardax Black Desktop USB CDC Virtual COM

RDR-6C81AK2pcProx 125 kHz Cardax Black Desktop Serial 5V PS2 RS232

RDR-6D81BK0pcProx 125 kHz Deister Black Desktop USB CDC Virtual COM

RDR-6D81AK2pcProx 125 kHz Deister Black Desktop Serial 5V PS2 RS232

RDR-6E81AK0pcProx 125 kHz EM 410x/Rosslare Black Desktop USB CDC Virtual COM

RDR-6E81AP0pcProx 125 kHz EM 410x/Rosslare Pearl Desktop USB CDC Virtual COM

RDR-6E81AK2pcProx 125 kHz EM 410x/Rosslare Black Desktop Serial 5V PS2 RS232

RDR-6E81AK5pcProx 125 kHz EM 410x/Rosslare Black Desktop Serial 5V Pin 9 RS232

RDR-6E81AK6pcProx 125 kHz EM 410x/Rosslare Black Desktop Serial 9V Pin 9 RS232

RDR-6E81AK7pcProx 125 kHz EM 410x/Rosslare Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6E81AK8pcProx 125 kHz EM 410x/Rosslare Black Desktop Serial 5V Ext Pwr Supply RS232

RDR-6EW1AK2pcProx 125 kHz EM 410x/Rosslare Black Surface Mount Serial 5V PS2 RS232

RDR-6EW1AK5pcProx 125 kHz EM 410x/Rosslare Black Surface Mount Serial 5V Pin 9 RS232

RDR-6EW1AK7pcProx 125 kHz EM 410x/Rosslare Black Surface Mount Serial 9V Ext Pwr Supply RS232

RDR-6G81AK0pcProx 125 kHz G-Prox II Black Desktop USB CDC Virtual COM

RDR-6G81AK2pcProx 125 kHz G-Prox II Black Desktop USB Serial 5V PS2 RS232

RDR-6G81AK5pcProx 125 kHz G-Prox II Black Desktop Serial 5V Pin 9 RS232

RDR-6G81AK7pcProx 125 kHz G-Prox II Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6GN1AK7pcProx 125 kHz G-Prox II Non-Housed Serial 9V Ext Pwr Supply RS232

RDR-6H81AK0pcProx 125 kHz HiTag Black Desktop USB CDC Virtual COM

RDR-6H81AK2pcProx 125 kHz HiTag Black Desktop Serial 5V PS2 RS232

RDR-6H81AK5pcProx 125 kHz HiTag Black Desktop Serial 5V Pin 9 RS232

RDR-6H81AK7pcProx 125 kHz HiTag Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6HW1AK2pcProx 125 kHz HiTag Black Surface Mount Serial 5V PS2 RS232

RDR-6K81AK0pcProx 125 kHz Keri Black Desktop USB CDC Virtual COM

RDR-6K81AK2pcProx 125 kHz Keri Black Desktop Serial 5V PS2 RS232

RDR-6K81AK5pcProx 125 kHz Keri Black Desktop Serial 5V Pin 9 RS232

RDR-6K81AK7pcProx 125 kHz Keri Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6KW1AK7pcProx 125 kHz Keri Black Surface Mount Serial 9V Ext Pwr Supply RS232

RDR-6N81AK0pcProx 125 kHz NexWatch (NexKey) Black Desktop USB CDC Virtual COM

RDR-6N81AK2pcProx 125 kHz NexWatch (NexKey) Black Desktop Serial 5V PS2 RS232

RDR-6N81AK5pcProx 125 kHz NexWatch (NexKey) Black Desktop Serial 5V Pin 9 RS232

RDR-6N81AK7pcProx 125 kHz NexWatch (NexKey) Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-6NW1AK0pcProx 125 kHz NexWatch (NexKey) Black Surface Mount USB CDC Virtual COM

RDR-6NW1AK2pcProx 125 kHz NexWatch (NexKey) Black Surface Mount Serial 5V PS2 RS232

RDR-6NW1AK5pcProx 125 kHz NexWatch (NexKey) Black Surface Mount Serial 5V Pin 9 RS232

RDR-6NW1AK7pcProx 125 kHz NexWatch (NexKey) Black Surface Mount Serial 9V Ext Pwr Supply RS232

RDR-6Z81AK0pcProx 125 kHz SecuraKey Black Desktop USB CDC Virtual COM

RDR-6Z81AK5pcProx 125 kHz SecuraKey Black Desktop Serial 5V Pin 9 RS232

pcProx 13.56 MHz USB Part Numbers

USBDescription

RDR-7011AKU pcProx 13.56 MHz HID™ iCLASS™, HID iCLASS SE, HID iCLASS SEOS PAC Black Vertical Nano USB

RDR-7012AKU pcProx 13.56 MHz 82 Series HID™ iCLASS™, HID iCLASS SE, HID iCLASS SEOS PAC Black Vertical Nano USB

RDR-7511AKU pcProx 13.56 MHz HID™ iCLASS™, ISO 14443A, MIFARE®, MIFARE DESFire®, ISO 15693 NFC1 (Topaz), FeliCa (NFC 3). ISO 14443B, CEPAS Black Vertical Nano USB

RDR-7512AKUpcProx 13.56 MHz 82 Series HID™ iCLASS™, ISO 14443A, MIFARE®, MIFARE DESFire®, ISO 15693 NFC1 (Topaz), FeliCa (NFC 3). ISO 14443B, CEPAS Black Vertical Nano USB

RDR-7081BKU (Replaces RDR-7081AKU)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop USB

RDR-7081BPUpcProx 13.56 MHz HID™ iCLASS™ Pearl Desktop USB

RDR-7082BKUpcProx 13.56 MHz 82 Series HID™ iCLASS™ Black Desktop USB

RDR-70N1BKUpcProx 13.56 MHz HID™ iCLASS™ Non-Housed USB

RDR-70W1BKUpcProx 13.56 MHz 82 Series HID™ iCLASS™ Black Surface Mount USB

RDR-7581AKUpcProx 13.56 MHz *CSN Black Desktop USB

RDR-7581APUpcProx 13.56 MHz *CSN Pearl Desktop USB

RDR-7582AKUpcProx 13.56 MHz 82 Series *CSN Black Desktop USB

RDR-75D2AKUpcProx 13.56 MHz *CSN Black USB Dongle

RDR-75N1AKUpcProx 13.56 MHz *CSN Non-Housed USB

RDR-75W1AKUpcProx 13.56 MHz *CSN Black Surface Mount USB

RDR-75W2AKUpcProx 13.56 MHz 82 Series *CSN Black Surface Mount USB

RDR-7F81AKUpcProx 13.56 MHz FeliCa Black Desktop USB

RDR-7F82AKUpcProx 13.56 MHz 82 Series FeliCa Black Desktop USB

RDR-7J81AKUpcProx 13.56 MHz Sielox Black Desktop USB

RDR-7J82AKUpcProx 13.56 MHz 82 Series Sielox Black Desktop USB

RDR-7L81AKUpcProx 13.56 MHz LEGIC Black Desktop USB

RDR-7L81APUpcProx 13.56 MHz LEGIC Pearl Desktop USB

RDR-7L82AKUpcProx 13.56 MHz 82 Series LEGIC Black Desktop USB

RDR-7W1AKUpcProx 13.56 MHz LEGIC Black Surface Mount USB

RDR-7P71AKUpcProx 13.56 MHz FIPS201 Black Desktop USB

RDR-7Y81AKUpcProx 13.56 MHz XceedID Black Desktop USB

RDR-7Y82AKUpcProx 13.56 MHz 82 Series XceedID Black Desktop USB

*CSN: MIFARE CSN, MIFARE DesFire CSN, iCLASS CSN, ISO-14443A CSN, ISO-15693A CSN

pcProx 13.56 MHz ExpressCard Part Numbers

ExpressCardDescription

RDR-70E1AKUpcProx 13.56 MHz HID™ iCLASS™ ExpressCard

RDR-70E2AKUpcProx 13.56 MHz 82 Series HID™ iCLASS™ ExpressCard

RDR-75E1AKUpcProx 13.56 MHz *CSN ExpressCard

RDR-75E2AKUpcProx 13.56 MHz 82 Series *CSN ExpressCard

*CSN: MIFARE CSN, MIFARE DesFire CSN, iCLASS CSN, ISO-14443A CSN, ISO-15693A CSN

pcProx 13.56 MHz Ethernet Part Numbers

EthernetDescription

RDR-7081BKE (Replaces RDR-7081AKE)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop Ethernet ASCII

pcProx 13.56 MHz Serial Part Numbers

SerialDescription

RDR-7081BK0 (Replaces RDR-7081AK0)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop USB CDC Virtual COM

RDR-7082BK0pcProx 13.56 MHz 82 Series HID™ iCLASS™ Black Desktop USB CDC Virtual COM

RDR-7081BK2 (Replaces RDR-7081AK2)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop Serial 5V PS2 RS232

RDR-7081BK5 (Replaces RDR-7081AK5)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop Serial 5V Pin 9 RS232

RDR-7081BK6 (Replaces RDR-7081AK6)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop Serial 9V Pin 9 RS232

RDR-7081BK7 (Replaces RDR-7081AK7)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-7081BK8 (Replaces RDR-7081AK8)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop Serial 5V Ext Pwr Supply RS232

RDR-7081BK9 (Replaces RDR-7081AK9)pcProx 13.56 MHz HID™ iCLASS™ Black Desktop Serial 5V USB Power Tap RS232

RDR-70N1BK0pcProx 13.56 MHz HID™ iCLASS™ Non-Housed USB CDC Virtual COM

RDR-70W1BK0pcProx 13.56 MHz HID™ iCLASS™ Black Surface Mount USB CDC Virtual COM

RDR-70W1BK2pcProx 13.56 MHz HID™ iCLASS™ Black Surface Mount Serial 5V PS2 RS232

RDR-70W1BK5pcProx 13.56 MHz HID™ iCLASS™ Black Surface Mount Serial 5V Pin 9 RS232

RDR-70W1BK7pcProx 13.56 MHz HID™ iCLASS™ Black Surface Mount Serial 9V Ext Pwr Supply RS232

RDR-70W1BK8pcProx 13.56 MHz HID™ iCLASS™ Black Surface Mount Serial 5V Ext Pwr Supply RS232

RDR-70W1BK9pcProx 13.56 MHz HID™ iCLASS™ Black Surface Mount Serial 5V USB Power Tap RS232

RDR-7581AK0pcProx 13.56 MHz *CSN Black Desktop USB CDC Virtual COM

RDR-7582AK0pcProx 13.56 MHz 82 Series *CSN Black Desktop USB CDC Virtual COM

RDR-7581AK2pcProx 13.56 MHz *CSN Black Desktop Serial 5V PS2 RS232

RDR-7581AK5pcProx 13.56 MHz *CSN Black Desktop Serial 5V Pin 9 RS232

RDR-7581AK6pcProx 13.56 MHz *CSN Black Desktop Serial 9V Pin 9 RS232

RDR-7581AK7pcProx 13.56 MHz *CSN Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-7581AK8pcProx 13.56 MHz *CSN Black Desktop Serial 5V Ext Pwr Supply RS232

RDR-7581AK9pcProx 13.56 MHz *CSN Black Desktop Serial 5V USB Power Tap RS232

RDR-75N1AK0pcProx 13.56 MHz *CSN Non-Housed USB CDC Virtual COM

RDR-75N1AK2pcProx 13.56 MHz *CSN Non-Housed Serial 5V PS2 RS232

RDR-75N1AK5pcProx 13.56 MHz *CSN Non-Housed Serial 5V Pin 9 RS232

RDR-75W1AK0pcProx 13.56 MHz *CSN Black Surface Mount USB CDC Virtual COM

RDR-75W1AK2pcProx 13.56 MHz *CSN Black Surface Mount Serial 5V PS2 RS232

RDR-75W1AK5pcProx 13.56 MHz *CSN Black Surface Mount Serial 5V Pin 9 RS232

RDR-75W1AK7pcProx 13.56 MHz *CSN Black Surface Mount Serial 9V Ext Pwr Supply RS232

RDR-75W1AK9pcProx 13.56 MHz *CSN Black Surface Mount Serial 5V USB Power Tap RS232

RDR-7F81AK0pcProx 13.56 MHz FeliCa Black Desktop USB CDC Virtual COM

RDR-7F81AK5pcProx 13.56 MHz FeliCa Black Desktop Serial 5V Pin 9 RS232

RDR-7J81AK7pcProx 13.56 MHz Sielox Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-7L81AK2pcProx 13.56 MHz LEGIC Black Desktop Serial 5V PS2 RS232

RDR-7L82AK2pcProx 13.56 MHz 82 Series LEGIC Black Desktop Serial 5V PS2 RS232

RDR-7L81AK5pcProx 13.56 MHz LEGIC Black Desktop Serial 5V Pin 9 RS232

RDR-7L81AK7pcProx 13.56 MHz LEGIC Black Desktop Serial 9V Ext Pwr Supply RS232

RDR-7Y81AK2pcProx 13.56 MHz XceedID Black Desktop Serial 5V PS2 RS232

RDR-7Y81AK5pcProx 13.56 MHz XceedID Black Desktop Serial 5V Pin 9 RS232

*CSN: MIFARE CSN, MIFARE DesFire CSN, iCLASS CSN, ISO-14443A CSN, ISO-15693A CSN

产品规格:

运行条件

工作频率: 125 kHz 或 13.56 MHz

典型最大读取范围: 1.0“ - 3.0”(2.5 - 7.6cm)取决于感应卡类型和环境条件。与pcProx读卡器相比,某些卡类型的性能略有下降。

工作台

物理特征

尺寸:工作台: 3 3/8“x 2”x 0.6“(8.57 x 5.08 x 1.52cm)。 125kHz纳米: 0.71“×0.62”×0.77“(垂直); 0.36”×0.62“×1.14”(水平)。 13.56 MHz纳米: 0.88“x 0.62”x 0.76“。

重量: 工作台: 4.0盎司(113.39克); 125 kHz 纳米: 0.14盎司; 13.56 MHz纳米: 0.20盎司。

外壳颜色:纳米 - 黑色; 桌面 - 黑色,珍珠; 表面贴装 - 黑色,白色; USB Dongle - 黑色; 键盘 - 黑色; 非安装,ExpressCard,PCMCIA - 如图所示

安装选项: 表面贴装外壳可以轻松安装在面板,信息和其他室内应用中。它设计用于仅安装1“#8螺钉(不包括在内),最大力为6.25英寸/磅。桌面阅读器具有铰接式电缆,可轻松放置在台式机,计数器等设备上。必须根据安装指南(随附所有装置)安装符合IP67标准的读卡器。

电缆长度: 6“,16”和60“(可定制长度。致电我们的销售部门,电话:(866)439-4884)

指示灯: 三态LED,双音蜂鸣器。(桌面和表面贴装提供双色调蜂鸣器)。 Nano:LED指示灯(水平版)

电源: USB自供电; 供电; 串行RS-232:存在多种电源选项

接口: USB,串行RS-232,以太网。Nano只是USB。

端口/样式: USB,USB Dongle,USB Nano,RS-232,以太网,键盘,OEM裸板

一般信息

认证: FCC,美国; CE Mark,欧洲; RCM,澳大利亚; IC-Industry Canada,UL。环境:RoHS,REACH。有关其他全球认证的更多信息,请联系sales@RFIDeas.com。

保修:材料/工艺缺陷一年。

分享到:
